Hospitality

Decorative Screen

Polyscreen® Vision Spice

Psv spice 002
Description Standards
Composition - 15% HT-PES + 85% PVC
Weight UNE EN 12127 609 g/m² (±5%) | 17.96 oz/yd²
Yarn / cm Internal Method Warp: 14 | Fill: 15
Yarn diameter Internal Method 0.4 mm | 0.016 in
Roll Width   250 cm | 98.4 in
UV blockage - Approximately 97%
Thickness (mm) UNE EN ISO 5084:1997 0.81 mm (±5%) | 0.032 in (±5%)
Light Fastness (gray scale level) UNE EN ISO 105 B06-2002 (interior)
UNE EN ISO 105 B03-1994(exterior)
UNE EN ISO 105 B04-1998(exterior)
UNE EN ISO 4892-2(exterior)
4/5
4/5
4/5
4/5
Light Fastness (blue scale level) UNE EN ISO 105 B02-2002 (interior) 7/8
Tearing Resistance (daN) UNE EN ISO 13937-3:2001 Warp: 7.4 | Weft: 7.7
Breaking Strength (daN/5cm) UNE EN ISO 13934-1:1999 Warp: 146.1 | Weft: 148.9
Stretch (%) UNE EN ISO 13934-1:1999 Warp: 23.1 | Weft: 23.3
Microorganism Growth Inhibition ASTM 2180-01 and ASTM G21-09 Yes
Corrosion in saline environment - Neutral fog UNE EN ISO 112-107:92
ISO 9227:90
Without changes in surface
Without changes in surface
Odor test PV-3900 3 Pass
Fire classification UNE EN 13773:2003
NFP 92-503
DIN 4102
NFPA 701
BS 5867:2:80
CLASS 1
M1
B1
Pass
Type C
Noise Reduction - Yes
Recycled Content - 2% Pre-Consumer

Cleaning and maintenance

1. Hand wash in cold water with a mild soap or damp cloth.

2. Vacuum clean for refular maintenance.

3. Do not use steam cleaning.

4. Do not use solvents.

Color Ts(%) Rs(%) As(%) Glass Control Night Privacy Visual Contact Daylight Utilisation
Class Class Class Class
Ash 14 47 39 1 2 1 2
Buckwheat 11 43 46 1 2 1 2
Linen 17 60 23 1 2 1 2
Natural 15 50 35 1 2 1 2
Sand 15 54 31 1 2 1 2
European Conformity
Vertilux 10 Years Warranty
Greenguard
Microterm
Vertilux 5 Years Warranty
Aitex
USGBC
Phthalates Free
Emas
Lead Free
NFPA 701
Oeko-Tex 100 Confidence in Textiles

VX Screen Stucco-8%

Ss stucco2
Description Standards
Composition - 30% PES + 70% PVC
Weight UNE EN 12127 420 g/m² (±5%) | 12.39 oz/yd²
Thickness UNE EN ISO 5084 0.70 mm (±5%) | 0.028 in (±5%)
Roll Width - 250 cm | 98.4 in
Openness Factor Int. Method- Approx. 8%
UV blockage Int. Method Approx. 92%
Mesh/in UNE EN ISO 13934-1:1999 Warp: 50 | Fill: 44
Fire Reaction NFPA 701 Pass
Environmental & Health Prorperties OEKO Tex® - 100 | Greenguard® Indoor Air Quality Certified





Screen 8%

Greenguard
Vertilux 5 Years Warranty
NFPA 701
Oeko-Tex 100 Confidence in Textiles

Polyscreen® Vision 310 Calico

Psv 310calico 003
Description Standards
Composition - 25% HT-PES + 75% PVC
Weight UNE EN 12127 337.20 g/m² (±5%) | 9.94 oz/yd²
Yarn / cm Internal Method Warp: 17 | Fill: 10.2
Yarn diameter Internal Method 0.3 mm | 0.012 in
Roll Width   250 cm | 98.4 in
UV blockage - Approximately 86%
Thickness (mm) UNE EN ISO 5084:1997 0.50 mm (±5%) | 0.020 in (±5%)
Light Fastness (Grey scale level)

UNE EN ISO 105 B06-2002 (interior)

UNE EN ISO 105 B03-1994 (interior)

UNE EN ISO 105 B04-1998 (exterior)

UNE EN ISO 4892-2 (exterior)

5/5

4/5 White

Light Fastness (Blue scale level) UNE EN ISO 105 B02-2002 (interior) 8/8 7/8 white
Tearing Resistance (daN) UNE EN ISO 13937-3:2001 Warp: 5.5 | Weft: 3.8
Breaking Strength (daN/5cm) UNE EN ISO 13934-1:1999 Warp: 162.3 | Weft: 109-4
Stretch (%) UNE EN ISO 13934-1:1999 Warp: 29.1 | Weft: 16.1
Fire classification UNE EN 13773:2003
NFP 92-503
DIN 4102
NFPA 701
CAN/UCL-S109-03/td>
CLASS 1
M1
B1
Pass
Pass
Corroosion in saline environment neutral fog UNE EN ISO 102-017:92 Whithout changes in surface (max. level)
Odor test PV-3900 3 Pass
Recycled content - 2% Pre-consumer
Antibacterial Activity ASTM 2180-01 and ASTM G21-09 Microorganism Growth Inhibition
Printable - Yes

1. Hand wash in cold water with a mild soap or damp cloth.

2. Vacuum clean for refular maintenance.

3. Do not use steam cleaning.

4. Do not use solvents.

Color % TV % RV % Av Glare Control Night Privacy Visual COntact Dalight Utilisation
White Sand 21 55 24 0 0 3 2
White Chocolate 20 47 33 0 0 3 2
White Ebony 18 43 39 0 0 4 2
European Conformity
Vertilux 10 Years Warranty
Greenguard
Microterm
Aitex
USGBC
Phthalates Free
Emas
Lead Free
NFPA 701
Oeko-Tex 100 Confidence in Textiles

Polyscreen® Vision Ensenada

Psv ensenada 001
Description Standards
Composition - 15% HT-PES + 85% PVC
Weight UNE EN 12127 557 g/m² (±5%) | 16.43 oz/yd²
Yarn / cm Internal Method Warp: 16 | Weft: 10
Yarn diameter Internal Method 0.4 mm | 0.016 in
Roll Width   250 cm | 98.4 in
UV blockage - Approximately 94%
Thickness (mm) UNE EN ISO 5084:1997 0.77 mm (±5%) | 0.030 in (±5%)
Light Fastness (gray scale level) UNE EN ISO 105 B06-2002 (interior)
UNE EN ISO 105 B03-1994(exterior)
UNE EN ISO 105 B04-1998(exterior)
UNE EN ISO 4892-2(exterior)
5/5 | 4/5 White
5/5 | 4/5 White
5/5 | 4/5 White
5/5 | 4/5 White
Light Fastness (blue scale level) UNE EN ISO 105 B02-2002 (interior) 8/8 | 7/8 White
Tearing Resistance (daN) UNE EN ISO 13937-3:2001 Warp: 6.8 | Weft: 4.1
Breaking Strength (daN/5cm) UNE EN ISO 13934-1:1999 Warp: 140 | Weft: 100
Stretch (%) UNE EN ISO 13934-1:1999 Warp: 24 | Weft: 21
Microorganism Growth Inhibition ASTM 2180-01 and ASTM G21-09 Yes
Corrosion in saline environment - Neutral fog UNE EN ISO 112-107:92
ISO 9227:90
Without changes in surface
Without changes in surface
Odor test PV-3900 3 Pass
Fire classification NFPA 701 Pass
Noise Reduction - Yes
Recycled Content - 2% Pre-Consumer

1. Hand wash in cold water with a mild soap or damp cloth.

2. Vacuum clean for refular maintenance.

3. Do not use steam cleaning.

4. Do not use solvents.

Color Ts(%) Rs(%) As(%) Glass Control Night Privacy Visual Contact Daylight Utilisation
Class Class Class Class
Cappuccino 10 50 40 1 1 2 2
Chocolate 09 44 47 1 1 3 1
Ebony 08 41 51 1 1 3 1
Linen 13 69 18 0 1 2 2
Sand 10 54 36 1 1 2 2
Skin 10 59 31 1 1 2 2
White 14 74 12 0 1 2 2
European Conformity
Vertilux 10 Years Warranty
Greenguard
Microterm
Aitex
USGBC
Phthalates Free
Emas
Lead Free
NFPA 701
Oeko-Tex 100 Confidence in Textiles

Polyscreen® Vision 310 Silken

Psv 310silver 001
Description Standards
Composition - 25% HT-PES + 75% PVC
Weight UNE EN 12127 337.20 g/m² (±5%) | 9.94 oz/yd²
Yarn / cm Internal Method Warp: 17 | Fill: 10.2
Yarn diameter Internal Method 0.3 mm | 0.012 in
Roll Width   250 cm | 98.4 in
UV blockage - Approximately 86%
Thickness (mm) UNE EN ISO 5084:1997 0.50 mm (±5%) | 0.020 in (±5%)
Light Fastness (Grey scale level)

UNE EN ISO 105 B06-2002 (interior)

UNE EN ISO 105 B03-1994 (interior)

UNE EN ISO 105 B04-1998 (exterior)

UNE EN ISO 4892-2 (exterior)

5/5

4/5 White

Light Fastness (Blue scale level) UNE EN ISO 105 B02-2002 (interior) 8/8 7/8 white
Tearing Resistance (daN) UNE EN ISO 13937-3:2001 Warp: 5.5 | Weft: 3.8
Breaking Strength (daN/5cm) UNE EN ISO 13934-1:1999 Warp: 162.3 | Weft: 109-4
Stretch (%) UNE EN ISO 13934-1:1999 Warp: 29.1 | Weft: 16.1
Fire classification UNE EN 13773:2003
NFP 92-503
DIN 4102
NFPA 701
CAN/UCL-S109-03/td>
CLASS 1
M1
B1
Pass
Pass
Corroosion in saline environment neutral fog UNE EN ISO 102-017:92 Whithout changes in surface (max. level)
Odor test PV-3900 3 Pass
Recycled content - 2% Pre-consumer
Antibacterial Activity ASTM 2180-01 and ASTM G21-09 Microorganism Growth Inhibition
Printable - Yes

1. Hand wash in cold water with a mild soap or damp cloth.

2. Vacuum clean for refular maintenance.

3. Do not use steam cleaning.

4. Do not use solvents.

Optical Properties

European Conformity
Vertilux 10 Years Warranty
Greenguard
Microterm
Aitex
USGBC
Phthalates Free
Emas
Lead Free
NFPA 701
Oeko-Tex 100 Confidence in Textiles
