Vertilux® Spec

Multifamily Residential

Screen 1%

Polyscreen® Vision 351-1%

Color Swatches
Technical properties
Cleaning and maintenance
Optical properties
Certificates

Polyscreen® Vision 351-1%

White

0-004-15-00298

Polyscreen® Vision 351-1%

Linen

0-004-15-00398

Polyscreen® Vision 351-1%

Bronze

0-004-15-00698

Polyscreen® Vision 351-1%

Ebony

0-004-15-01998

Polyscreen® Vision 351-1%

White Pearl

0-004-15-02798

Polyscreen® Vision 351-1%

White Linen

0-004-15-22098

Description	Standards
Composition	-	20% HT-PES + 80% PVC
Weight	UNE EN 12127	453 g/m² (±5%) \| 13.36 oz/yd²
Yarn / cm	Internal Method	Warp: 22 \| Fill: 18.5
Yarn diameter	Internal Method	0.3 mm \| 0.012 in
Roll Width		250 cm \| 98.4 in
UV blockage	-	Approximately 99%
Thickness (mm)	UNE EN ISO 5084:1997	0.59 mm (±5%) \| 0.023 in (±5%)
Light Fastness (gray scale level)	UNE EN ISO 105 B06-2002 (interior) UNE EN ISO 105 B03-1994 (exterior) UNE EN ISO 105 B04-1998 (exterior) UNE EN ISO 4892-2 (exterior)	5/5 \| 4/5 White 5/5 \| 4/5 White 5/5 \| 4/5 White 5/5 \| 4/5 White
Light Fastness (blue scale level)	UNE EN ISO 105 B02-2002 (interior)	8/8 \| 7/8 White
Tearing Resistance (daN)	UNE EN ISO 13937-3:2001	Warp: 5.1 \| Weft: 3.6
Breaking Strength (daN/5cm)	UNE EN ISO 13934-1:1999	Warp: 171.8 \| Weft: 140.8
Stretch (%)	UNE EN ISO 13934-1:1999	Warp: 30.1 \| Weft: 19.7
Microorganism Growth Inhibition	ASTM 2180-01 and ASTM G21-09	Yes
Corrosion in saline environment - Neutral fog	UNE EN ISO 112-107:92 ISO 9227:90	Without changes in surface Without changes in surface
Odor test	PV-3900	3 Pass
Fire classification	UNE EN 13773:2003 NFP 92-503 DIN 4102 NFPA 701 CAN/UCL-S109-03/td>	CLASS 1 M1 B1 Pass Pass
Wheelmark	IMO Resolution MSC.307 (88) - (2010 FTP Code) and IMO MSC/Circ. 1102	Pass
Noise Reduction	-	Yes
Recycled Content	-	2% Pre-Consumer

1. Hand wash in cold water with a mild soap or damp cloth.

2. Vacuum clean for refular maintenance.

3. Do not use steam cleaning.

4. Do not use solvents.

Color	Ts(%)	Rs(%)	As(%)	Tv(%)	gTot Internal Grazing C		gTot Internal Grazing D		Glare Control	Night Privacy	Visual Contact	Daylight Utilisation
Color	Ts(%)	Rs(%)	As(%)	Tv(%)	gTot	Class	gTot	Class	Class	Class	Class	Class
Bronze	04	07	89	05	0.49	1	0.28	2	2	2	1	1
Ebony	03	04	93	03	0.50	0	0.28	2	3	2	2	1
Ebony Grey	04	08	88	04	0.49	1	0.28	1	3	2	2	1
Linen	21	57	22	16	0.35	1	0.24	2	1	2	1	2
White	18	70	12	14	0.32	2	0.23	2	1	2	1	2
White Grey	08	41	51	07	0.39	1	0.25	2	2	2	2	1
White Linen	19	65	16	14	0.33	2	0.23	2	1	2	1	2
White Pearl	10	57	33	10	0.35	1	0.24	2	1	2	1	1

Add to wishlist
Share

VX Screen 5000-1%

Color Swatches
Technical properties
Cleaning and maintenance
Optical properties
Certificates

VX Screen 5000-1%

White

0-004-64-00298

VX Screen 5000-1%

White Linen

0-004-64-22098

VX Screen 5000-1%

White Grey

0-004-64-02198

VX Screen 5000-1%

Slate

0-004-64-00698

VX Screen 5000-1%

Chocolate

0-004-64-00898

Description	Standards
Composition	-	30% PES + 70% PVC
Weight	UNE EN 12127	810 g/m² (±5%) \| 23.89 oz/yd²
Thickness	UNE EN ISO 5084	1.08 mm (±5%) \| 0.043 in
Roll Width	-	250 cm \| 98 in
Openness Factor	Int. Method-	Approx. 1%
UV blockage	Int. Method	Approx. 99%
Tensile Strength	-	Warp: 291.5 \| Fill: 100.3
Fire Reaction	NFPA 701	Pass
Environmental & Health Prorperties	OEKO Tex® - 100	Certified

Color	Ts(%)	Rs(%)	As(%)
White	N/A	N/A	N/A
White Linen	N/A	N/A	N/A
White Grey	N/A	N/A	N/A
